Custom Sheet Metal Fabrication Services
From initial concept to final assembly, we deliver precision, quality, and partnership.
- Laser Cutting
✧ Precision 2D & Tube Cutting for aluminum, stainless & carbon steel.
✧ Clean edges, tight tolerances for automotive, electronics & machinery parts.
2. CNC Bending
✧ High-accuracy forming of sheets & tubes.
✧ From prototype to production, handling complex geometries with ease.
3. Expert Welding
✧ Manual TIG/MIG for custom assemblies.
✧ Robotic welding for high-volume, consistent quality.
4. Finishing & Assembly
✧ Aesthetic & protective finishes: Powder coating, anodizing, plating.
✧ Turnkey assembly services, meeting Western export standards.
5. Tooling & Prototyping
✧ Rapid in-house tool design and low-volume production.
✧ Accelerate your product development cycle from validation to launch.
Advanced Laser Processing & Fabrication of Stainless Steel Sheet and Tube
We utilize fiber laser cutting technology for high-precision, non-contact processing of stainless steel sheets and tubes.
- Burr-Free Plate Cutting: Achieves smooth edges that eliminate secondary grinding, saving time and cost in subsequent processing.
- Precision Tube Fabrication: Handles cutting, grooving, and punching of round, square, and rectangular tubes while preventing deformation.
- Rapid Prototyping: Provides 24-hour sample turnaround for small batches and urgent custom projects.
| Processing type | Applicable thickness/Diameter range | Precision tolerance | Supported materials |
| Stainless steel sheet | 0.5 mm – 20 mm | ± 0.05 mm | 304/316/430 & all stainless steel grades |
| Stainless steel tube | 10 mm – 150 mm | ± 0.1 mm | Round/Square/Rectangular tubes |
Complex Profile Bending of Stainless Steel Sheet & Tube | Maintaining Material Integrity
We address the common issues of angle inaccuracy and surface marring in conventional bending by employing CNC press brakes with dedicated stainless steel tooling. This ensures precise, damage-free bending of both sheets and tubes.
Sheet Bending: Capable of complex angles (0°-180°) and multi-stage bends. Protective film is applied to prevent surface scratches.
Tube Bending: Performs arc and right-angle bends on round and square tubing while preventing wrinkling or collapse.
Custom Tooling: Dedicated molds are engineered for unique part geometries to guarantee consistent, repeatable results
| Processing type | Applicable range | Angle precision | Min bend radius |
| Stainless steel sheet | Thickness 0.5 mm – 15mm | ± 0.5° | 1.5 × sheet thickness |
| Stainless steel tube | Diameter 10 mm – 100 mm | ± 1° | 3 × tube diameter |
Comprehensive Stainless Steel Welding Solutions: Precision Hand Welding & Robotic Automation
We integrate manual precision welding with robotic automation to definitively solve issues of weak fusion, part distortion, and poor aesthetics.
✅ Certified, Verifiable Quality
All welding conforms to AWS D1.6 structural stainless steel code. Third-party testing is welcomed.
✅ No Thermal Distortion
Combination of rigid custom fixtures and low-heat input welding processes prevents workpiece warping.
✅ Intelligently Allocated Process
Manual Welding: Chosen for complex geometries, prototypes, and small batches requiring adaptability.
Robotic Welding: Selected for large-volume standard parts to deliver unmatched speed and consistency.
| Welding process | Advantages | Supported weld types |
| Manual precision welding | Fits complex shapes & narrow spaces | Fillet weld, groove weld, seal weld |
| Robotic automation Welding | High weld consistency, 30% efficiency boost | Straight weld, circumferential weld, repetitive welds |
